Technical specifications
Remote particle counter with built-in blower
| Minimum particle size | 0.3 µm |
|---|
| Number of channels | 6 (0.3 / 0.5 / 1.0 / 3.0 / 5.0 / 10.0 µm) |
|---|
| Sampling flow rate | 28.3 L/min |
|---|
| Housing | Stainless steel 316L |
|---|
| Supply voltage | 24 V DC, max. 70 W |
|---|
| Internal storage capacity | > 10,000 records |
|---|
| Dimensions (W × D × H) | 200 × 127.50 × 164.10 mm |
|---|
| Weight | 2.0 kg |
|---|
| Communication | RS-485 / Ethernet, Modbus RTU/TCP, MQTT (client), 4-20 mA; Wi-Fi only on S-RPC-P28-4EW |
|---|
